Carbon Tub for Noble

Carbon Tub for Noble

Author	Message
andygtt	andygtt posted 12 Years Ago HOT Post Details
Group: Forum Members Posts: 157, Visits: 1.2K	I looked carefully at the rocker cover with the intention to make canon ones (I had carbon ones designed and made for my Ultima by Reverie around 10 years ago)... however the noble ones are way too complex a shape to attempt and they are sided so would have been a huge amount of work... Carbon inlet manifold is a possibility though. I haven't considered the sump for the reasons Warren identified... plus its already alloy so fairly light and we are currently doing a redesign of it due to some surge even with the huge winged one I have now.... the benefit of metal that warren didn't mention is that it also cools the oil which a carbon sump wouldn't do.
	Reply Like 2
Warren (Staff)	Warren (Staff) posted 12 Years Ago HOT Post Details
Group: Administrators Posts: 2.5K, Visits: 8.5K	Often you are best designing the part from scratch rather than copying the alloy cast original as they can get away with more complex shapes and logos in a cast part than composite. If i made a camcover in the future it would be my own design, based on factory dimensions so its easy to mould. Warren Penalver Easy Composites / Carbon Mods - Technical Support Assistant
	Reply Like 2
wojtepanik	wojtepanik posted 12 Years Ago HOT Post Details
Group: Forum Members Posts: 102, Visits: 582	andygtt (10/12/2013) wojtepanik (10/12/2013) Hi So you are doing something like monocoque? because I am not sure what more can be done here with carbon maybe wheels I started making the moulds for my carbon seats a few weeks back, also made a diffuser which is nearly finished.... so there is always things left to make from carbon. However Im not sure my composite skills are up to making wheels lol Do you make your diffuser from scracht? Do you put some naca ducts on your pannels maybe? Do you have flat bottom of your car? because otherwise diffuser doesn't make any sense ~~~Everytime I hear sound of demoulding part I have eargasm~~~
	Reply Like 2
pk_090	pk_090 posted 12 Years Ago HOT Post Details
Group: Forum Members Posts: 47, Visits: 169	Haven't posted on this forum in a loooooon time but i think this is really worthy. I love what you are doing here Andy! What engine specs are you going for? Also just to add this spanner to the works, a friend of mine works for the company that provides f1 teams with their pre-preg. He told me that red bull racing cam covers were 1 layer thick of normal pre-preg carbon. Obviously i can say this is 100% accurate but i can see why they do it! Alex
	Reply Like 3
andygtt	andygtt posted 12 Years Ago HOT Post Details
Group: Forum Members Posts: 157, Visits: 1.2K	the entire car underside is flat, I made the diffuser from scratch and of cause it had to be in V weave. Here is a pic of it upside down on the kitchen table and a pic of the mould I make from MDF
	Reply Like 3
andygtt	andygtt posted 12 Years Ago HOT Post Details
Group: Forum Members Posts: 157, Visits: 1.2K	pk_090 (12/12/2013) Haven't posted on this forum in a loooooon time but i think this is really worthy. I love what you are doing here Andy! What engine specs are you going for? Also just to add this spanner to the works, a friend of mine works for the company that provides f1 teams with their pre-preg. He told me that red bull racing cam covers were 1 layer thick of normal pre-preg carbon. Obviously i can say this is 100% accurate but i can see why they do it! Alex glad you like it, and thanks for the info... the engine is already 700bhp, its unique in the UK as its a single turbo that I designed myself with my own design of clutch package.... car is a real 1off in almost all areas. To be honest all the mods on this car is simply R&D for my scratch build car that I have designed and been building forever lol.
	Reply Like 3
andygtt	andygtt posted 12 Years Ago HOT Post Details
Group: Forum Members Posts: 157, Visits: 1.2K	I started making the barriers for the first mould section.... Care must be taken to ensure the mould will release from both the buck AND the final part. You will always make the final part slightly oversize so it's very easy to accidentally get a lock on the overlap or the other mould sections. Current plan is for this to be 9 sections ( my rear clip was 12).... So far I have got the first layer of the gel coat down, another coat tomorrow morning and then I can do the coupling coat.
	Reply Like 3
Warren (Staff)	Warren (Staff) posted 12 Years Ago HOT Post Details
Group: Administrators Posts: 2.5K, Visits: 8.5K	Looking good Andy!! Under the fibreglass tub is there a metal spaceframe or is it a true structural composite centre tub on nobles?? Warren Penalver Easy Composites / Carbon Mods - Technical Support Assistant
	Reply Like 3
andygtt	andygtt posted 12 Years Ago HOT Post Details
Group: Forum Members Posts: 157, Visits: 1.2K	Its a space frame so the tub isn't structural... Once I have removed the original tub I am going to replace all the alloy panels with carbon ones
	Reply Like 3
Warren (Staff)	Warren (Staff) posted 12 Years Ago HOT Post Details
Group: Administrators Posts: 2.5K, Visits: 8.5K	Not thinking of cutting out the space frame and making a semi-monocoque centre tub in carbon then?? Im going the whole hog with my project but it will take a while!! Warren Penalver Easy Composites / Carbon Mods - Technical Support Assistant
	Reply Like 3
